+ Elegant and space-saving design for mATX motherboards
+ Seamless cable management with cutouts for Back-Connect motherboards
+ Tempered glass side panel provides a discreet appearance
+ Ample space for cooling solutions allows for the installation of powerful hardware
+ Three dust filters protect your hardware from pesky dust particles
Powerful cooling in a small space
To ensure that your powerful hardware is adequately cooled even in the compact case, Jonsbo has developed an optimal cooling solution for the available space. With six 120 mm fans for sufficient airflow, a large dual-tower CPU cooler, or even an installable 240 mm AIO, your hardware remains cool even under load.
Three dust filters at the front, the top, and the bottom ensure that your hardware stays free from dust and dirt. This keeps your temperatures at optimal levels and also extends the lifespan of your hardware.
Dimensions | |
Length / Depth | 396 mm |
Width | 207 mm |
Height | 314 mm |
Weight | 4.6 kg |
Case | |
Case Type | Mini Case |
Motherboard Support | |
Compatible Motherboard Formats | Micro-ATX, Mini-ITX |
Max. Motherboard Format | Micro-ATX |
Internal Dimensions | |
Max. CPU Cooler Height | 170 mm |
Max. GPU Length | 365 mm |
Max. PSU Length / Depth | 200 mm |
Display | |
Display Included | No |
Power Supply | |
PSU included | No |
PSU Format | ATX, SFX |
Power Supply Position | front |
Fan Support | |
Max. Number of Fans | 6 |
120 mm fans | 6 |
140 mm fans | 4 |
Radiator Support | |
Max. Radiator Compatibility | 1x Dual (240 mm) |
Drive Bays | |
Max. 2.5 Inch Drives | 3 |
Max. 3.5 Inch Drives | 2 |
Max. 5.25 Inch Drives | |
2.5 inch internal drive bay | 2 |
3.5 inch internal drive bay | 1 |
1x 3.5 / 1x 2.5 Inch Internal Drive Bays (combined) | 1 |
Hot swap drive bays | No |
External Ports | |
USB 3.1 (external) Type C | 1 |
USB 3.0 (external) Type A | 2 |
Audio outputs & inputs | 1x output / input comb. (3.5 mm jack, 4-pin, TRRS) |
Card reader | No |
Case Features | |
I/O position | Front |
Side panel | with window |
Vertical GPU Mount | No |
Adjustable Vertical GPU Bracket | No |
Riser Cable Included | No |
Front door | No |
Cable Management | Yes |
Filters Included | Yes |
Filter Position | Bottom, Side, Top |
Noise dampening | No |
Mainboard slide / tray | No |
Transport System | No |
Back Connect | |
Back Connect | Yes |
Back-Connect Compatibility | ASUS BTF, Gigabyte Project Stealth, MSI Project Zero |
Expansion Slots | |
Expansion slots / PCI slots | 4 |
PCI slot allocation | 2x 2 |
Features | |
Housing Feedthrough | No |
Compatibility | |
Compatibility Note | Please refer to the manufacturer's compatibility information. You can find the latest overview on the manufacturer's website. |
Fan Header | |
Fan Controller / Fan Hub | No |
Mounting | |
Case VESA Mountable | No |
Internal Monitor Mount | No |
Materials | |
Materials | Aluminium, Plastic, Steel |
