Motherboard Support
up to E-ATX (285 mm wide)
Fan Support
Top: 3x 120 mm | 3x 140 mm
Side: 3x 120 mm | 3x 140 mm (included)
Rear: 2x 120 mm (included)
Radiator Support
Top: 240 / 280 / 360 / 420 mm
Side: 240 / 280 / 360 / 420 mm
CPU Cooler up to 171 mm
PSU ATX up to 318 mm (200 mm with HDD Cage)
GPU up to 482 mm (337 mm with Side Radiator)
Front I/O
USB-C (USB 3.2 Gen2x1 - 10 Gbps)
2x USB-A (USB 3.2 Gen1x1 - 5 Gbps)
3.5 mm Jack (Line-In/Out)
Power Button
Net Weight 15.4 kg
Volume 64 l
Dimensions 529 (L) x 231 (W) x 529 (H) mm
Drive Bays Behind the Mainboard Tray: 3× 2,5"
HDD Cage: 2x 3,5" or 2,5" + 1x 2,5"
PCI Slots 7
Cable Management Space 35 mm
Dust Filters Top, Right Side
PSU RGB Stripe Specifications
LEDs 24 × A-RGB Gen 2 LEDs
Current | Voltage 0.89 A | 5 V DC
Connector 3-Pin A-RGB Plug + Socket
Fan Specification
2x P12 Pro A-RGB (pre-installed at rear)
Speed 600–3000 rpm
Air Flow 77 cfm | 131 m³/h
Static Pressure 6.9 mmH2O
Bearing Fluid Dynamic Bearing
Current | Voltage 0.33 A | 12 V DC
Connector 4-Pin Fan Plug + Socket
RGB Specifications
LEDs 12x A-RGB Gen 2 LEDs
Current | Voltage 0.40 A | 5 V DC
Connector 3-Pin A-RGB Plug + Socket
3x P14 Pro Reverse A-RGB (pre-installed at side)
Speed 400–2650 rpm
Airflow 98 cfm | 166.5 m³/h
Static Pressure 5.1 mmH2O
Bearing Fluid Dynamic Bearing
Current | Voltage 0.40 A | 12 V DC
Connector 4-Pin Fan Plug + Socket
RGB Specifications
LEDs 12 x A-RGB Gen 2 LED
Current | Voltage 0.40 A | 5 V DC
Connector 3-Pin A-RGB Plug + Socket
Vertical GPU Mounting Kit Specification
Dimensions 196 (L) x 153 (W) x 140 (H) mm
Supported Graphics Cards Up to 482 mm Length and 3-Slot Mounting
Compatibility PCIe 4.0 and Backward Compatible
Riser Cable 160 mm, PCIe 4.0 x16
PCI Slots Required 7
